Hyper Achromatic X RCA Subwoofer
Advanced OCC copper interconnect. 1:1 & 1:2 versions.
Today’s sophisticated subwoofers for both audio and home cinema installations demand fast, accurate low frequency performance free of external RF (radio frequency) and EM (electro-magnetic) interference and noise picked up by the cable itself (usually heard as hum).
The Hyper Achromatic Sub features high purity OCC (Ohno Continuous Casting) copper encapsulated within a low-loss foamed PEF (Foamed Polyethylene) dielectric, ensuring excellent immunity to interference and noise, making it ideally suited to longer cable runs of up to 10m.
Available in 1:1 and 1:2 configurations.
Key Features. Essential characteristics of this product.
Technology
Engineered
Performance
Atlas Essentials +
Product Specifications.
| Construction | Coaxial (1:1); Multicore (1:2) |
| Conductor | OCC Copper |
| Dielectric | Microporous PTFE |
| Screen | Foil/OFC braid; Dual Drain (1:2) |
| Capacitance | 73.828 pF/m |
| Inductance | 1.130 µH/m |
| Resistance | 0.023054 Ohms/m |
| Outside Diameter | 9 mm (1:1); 10.2 mm (1:2) |
| Colour/Finish | Gloss Black |
